Brass Nylon Insert Lock Nut

Product Description

Nylon Insert Lock Nut (Nyloc Nut)

A Nylon Insert Lock Nut, commonly referred to as a Nyloc nut, is a specialized torque-prevailing fastener designed to resist loosening under conditions of severe vibration and dynamic loads. Unlike standard hex nuts, the Nyloc nut features a distinctive integrated collar that houses a captive nylon ring.

Internal Mechanism and Functionality

The locking action of the nut is mechanical rather than chemical. When a bolt is threaded into the nut, it encounters the nylon insert at the top of the hexagonal body.

1. Interference Fit: The internal diameter of the nylon ring is slightly smaller than the major diameter of the matching bolt.

2. Thread Compression: As the bolt penetrates the nylon, it does not "cut" threads into the plastic; instead, the nylon deforms elastically around the bolt threads.

3. Radial Friction: This compression creates a tight, 360-degree frictional grip (prevailing torque) that keeps the nut in a fixed position even when the assembly is not under tension.

Key Technical Advantages

• Vibration Resistance: Standard nuts can "walk" off a bolt due to thermal expansion or mechanical oscillation. The nylon insert maintains a constant grip, preventing accidental disassembly.

• Sealing Properties: The tight fit of the nylon against the bolt threads provides a secondary benefit by helping to seal against the seepage of water, oil, or cleaning solvents along the thread path.

• Non-Damaging: Unlike "all-metal" locking nuts that use deformed threads to create friction, the nylon insert is relatively gentle on the bolt's surface, reducing the risk of galling or stripping.

• Temperature Range: Typically rated for consistent performance up to 120C (248F), making them suitable for most industrial and automotive environments.

Common Industrial Applications

Nylon insert lock nuts are the industry standard for safety-critical assemblies where fastener failure is not an option:

• Automotive & Transport: Used extensively in suspension systems, engine mounts, and chassis assembly.

• Manufacturing Equipment: Ideal for conveyors, rotating shafts, and vibrating machinery.

• Electrical Enclosures: Frequently paired with brass or stainless steel hardware in control panels to ensure connections remain tight over years of service.

• Consumer Goods: Found in high-stress items like bicycles, lawnmowers, and exercise equipment.

Note on Reusability: While Nyloc nuts can be reused, their prevailing torque decreases with each installation as the nylon insert becomes permanently deformed. For critical safety applications, it is recommended to use a new nut during every reassembly to ensure maximum locking efficiency.
