BRASS EARTH BAR
Product Details:
- Product Type Other
- Style Industrial Electrical
- Material Capabilities Other
- Surface Treatment Electro-Polished
- CNC Machining Available
- Size MULTI
- Dimension (L*W*H) 200mm x 25mm x 6mm (Typical), Custom sizes on request
- Click to View more
BRASS EARTH BAR Price And Quantity
- 1150.0 INR/Kilograms
- 1000 Kilograms
BRASS EARTH BAR Product Specifications
- Other
- Industrial Electrical
- BRASS
- Available
- Golden Yellow
- Electro-Polished
- Other
- 200mm x 25mm x 6mm (Typical), Custom sizes on request
- MULTI
- Solid and Stranded
- -10C to +120C
- 8 to 24 (Custom Configurations Possible)
- Electrical Panel, Switchboard, Distribution Board
- Up to 400A (Depending on size and design)
- Excellent due to brass composition
- Insulated Base/Direct Mount
- Smooth, Bright with Burr Free Edges
BRASS EARTH BAR Trade Information
- Cash in Advance (CID)
- 5000 Kilograms Per Month
- 2 Week
- Sample costs shipping and taxes has to be paid by the buyer
- Asia, Western Europe, Australia, Central America, North America, South America, Eastern Europe, Middle East, Africa
- All India
Product Description
A brass earth bar (or grounding bar) serves as the primary junction point for grounding systems within an electrical installation. It provides a reliable, low-impedance path to the earth, ensuring that fault currents are safely diverted away from equipment and personnel to prevent electric shocks and fires.
Material and Construction
Manufactured predominantly from high-tensile brass alloys, such as CZ121 or CW614N, these components are chosen for their high copper content, which ensures excellent electrical conductivity. Unlike copper, brass offers superior mechanical rigidity, making it less prone to bending during the high-torque tightening of heavy-gauge cables. To combat galvanic corrosionparticularly when connecting dissimilar metals like aluminum or copper lugsbars are frequently tin-plated.
Key Components
-
Main Bar: A solid rectangular or square section of brass, pre-drilled and tapped at regular intervals.
-
Disconnecting Link: Many industrial earth bars include a removable link. This allows for the isolation of the grounding system from the main earth electrode for periodic testing of earth resistance without disconnecting all individual circuits.
-
Fasteners: High-quality brass or stainless steel bolts and washers ensure that connections remain tight and vibration-resistant over time.
Applications and Utility
Earth bars are central to the safety infrastructure of:
-
Data Centers: Protecting sensitive server racks from electrostatic discharge (ESD).
-
Industrial Switchgear: Managing high fault currents in heavy machinery environments.
-
Lightning Protection Systems: Interconnecting down-conductors to the earth pit.
Advantages
The use of a dedicated brass earth bar simplifies wire management and inspection. By centralizing all grounding conductors, it allows maintenance teams to quickly verify the integrity of the grounding system. Its robust construction ensures it can withstand the thermal stresses associated with short-circuit events, making it a "safety-critical" component in any modern electrical distribution network.
Versatile Terminal Configurations
Choose from 8 to 24 terminal options, or request a custom configuration to meet unique installation requirements. The bar is designed to be adaptable, making it suitable for a wide array of electrical distribution setups, whether for new projects or retrofit applications.
Reliable Brass Construction
Crafted from premium brass, this earth bar delivers outstanding conductivity and corrosion resistance. Its electro-polished surface enhances durability, and the burr-free edges ensure safe, easy installation. This makes it an optimal choice for demanding industrial environments.
FAQ's of BRASS EARTH BAR:
Q: How is the BRASS EARTH BAR installed in electrical panels?
A: Installation can be done with either an insulated base for added protection or by direct mounting, depending on your system's requirements. The bar comes with standard fitting holes for secure and straightforward setup.Q: What type of conductors can be connected to this earth bar?
A: The bar accepts both solid and stranded conductors, providing versatility for a range of wiring schemes commonly used in industrial, commercial, and residential panels.Q: When should I select a custom configuration for terminals?
A: If your project demands a specific number of terminals not covered by standard 8 to 24 options, or if your layout requires unique spacing, a custom configuration is ideal. Custom requests can better align the earth bar with your installation needs.Q: Where is the BRASS EARTH BAR best applied?
A: It is primarily used in electrical panels, switchboards, and distribution boards to safely consolidate earth conductors. Its robust and adaptable design makes it suitable for various industries and environments.Q: What benefits does the brass material provide?
A: Brass offers excellent current conductivity and remarkable resistance to corrosion, ensuring longevity and reliable performance even in challenging electrical environments.Q: How does the electro-polished finish improve the product?
A: Electro-polishing creates a smooth, bright surface free from burrs, reducing installation hazards and further enhancing corrosion protection for extended service life.Q: What is the process for requesting CNC machining or custom dimensions?
A: Simply contact the manufacturer or supplier with your specific requirements. CNC machining enables precise customization, allowing the earth bar to match unusual space constraints or specialized terminal needs.
